Place of Origin:
Shandong,China
Brand Name:
None
Certification:
CE/ISO9001:2000/SGS/Euro 5
Model Number:
FW08
Contact Us
Our excavator is also designed with safety in mind. The robust structure of the machine ensures it can handle tough terrain and heavy loads with ease, while the advanced monitoring systems keep the operator informed about the machine's performance and safety features.
In addition, the machine has been designed for easy maintenance. The straightforward design of the machine and the easily accessible service points make maintaining the excavator simple and efficient, contributing to a reduced total cost of ownership.
In conclusion, our excavator is a powerful and reliable machine that can handle any construction, excavation, or earthmoving task. With a top-of-the-line hydraulic system, efficient engine, advanced cab, and excellent safety features, the excavator is equipped to maximize productivity while ensuring operator comfort and safety. Contact us to learn more about how our excavator can help your construction business reach new heights.
| Preformance Parameter FW08A | |
| Rated Power | 7kw-7.5kw |
| Bucket Capacity | 0.025m³ |
| Bucket Width | 300mm |
| Engine Model | Koop192f |
| Optional Engine | Briggs&Stratton |
| Opeating Weight | 800kg |
| Pump Form | Single Gear Pump |
| Set Working Pressure | 14Mpa |
| Swing Speed | 12rpm |
| Travel Speed | 2.2Km/h |
| Gradeability | 30° |
| Ground Pressure | 19Kpa |
| Max. Digging Force | 7.5Kn |
| Dimensions | |
| Total Width | 720-780mm |
| Total Height | 1300mm |
| Total Length | 2430mm |
| Min.Ground Clearance | 80mm |
| Track Ground Length | 1140mm |
| Track Width | 150mm |
| Working Range | |
| Max.Digging Distance | 2450mm |
| Max.Digging Depth | 1200mm |
| Max.Digging Height | 2350mm |
| Max.Dumping Height | 1600mm |
| Min. Swing Radius | 1100mm |
| Max. upgrade Height of Bulldozer Blade | 120mm |
| Max.Digging Depth of Bulldozer Blade | 200mm |
